Feature

Drive Motor

Power(P1)

Y/Y2 Induction Motor, 4.0Kw~820Kw

Voltage Scope(V)

110V~660V or make specially according to clients’requirement.

Phase

Single(under 3Kw) or Three

Pole

2 or 4 or 6 or 8 or 10

Motor Speed(N1)

Relys on motor pole:600r/min~3000r/min

Frequency

50Hz or 60Hz or 50/60Hz

Insulation Class

F

IP

IP54 or IP55 or make specially according to clients’ requirement.

Duty

S1

Cooling Type

IC0141(Fan Self-cooling) or Blower

Terminal Box

0º or 90º or 180º or 270º,any position is allowed

Link Wire

Y(P1≤3Kw),  Δ(P1>3Kw)

Operation Temperature

Normally:-15℃~ 40℃.If end-user’s special requirement,we’ll make it specially.

Structure

Right-angled shaft

Size

1~22

Input Shaft

Solid(firm) input shaft

Connect Method

IEC motor adapter

Output Shaft

Solid(firm) output shaft

Ratio Scope(i)

2-stage

5.0~18

3-stage

20~71

4-stage

80~400

Rated Torque(N.m)

1000N.m~470000N.m

Output Speed(N2)

Depends on input speed: N2=N1/ratio(i)

Service Factor(Fs)

1.5~5.0

Mount Type

Horizontal

Vertical

Please consider if need oil pump
